Features:
1. Stainless steel DDC with 12 steam injectors and 6 liquid nozzles.
2. The gearbox can stand strong torque and thrust up to 400hp.
3. Circled tunnel design barrel with liner can achieve heating/cooling function. Steam and water can also be injected directly into the barrel.
4. Screw is made of special anti-wear alloy with L/D ratio up to 19.5:1 that assures smoothly production for all kinds of sinking/floating feed.
5. It can deal with different formulation . It can produce pellet with die diameter from
5. Fast replacing mechanism for die and screw and on-line adjustment for cutter.
Main Technical Parameters:
|
Model |
Main Power (KW) |
Feeder Power (KW) |
Conditioner Power (KW) |
Cutter Power (KW) |
Capacity (T/H) |
|
TSE68 |
55/75 |
1.5 |
5.5 |
3 |
0.5~1.8 |
|
TSE98 |
90/110 |
1.5 |
11 |
4 |
1.5~3 |
|
TSE128 |
160/200 |
2.2 |
18.5 |
5.5 |
3.0~7.0 |
|
TSE148 |
250/315 |
2.2 |
22 |
7.5 |
6.0~12.0 |
