Features
1. The mixing chamber is “W” horizontal shell shape, Double shafts and many paddles. The spraying system (spray nozzle & fittings)which is on top of mixer can meet light and heavy bulk density materials mixing, improve the liquid atomizing and prevent from agglomerating;
2. Specially designed discharger has big door-opening angle and quick discharging with little residue. Good tightness and no products leakage;
3. High mixing speed and high homogeneity. It makes materials mixed and is not influenced for bulk density, filling degree in state of loss weight;
4. It is widely used for mixing of powdered, granular, flaky, blocky, irregular and sticky materials in the industries of feed, cereal, food, chemicals, medicines, pesticides, etc.
Main Technical Features
|
Parameters Model |
Volume
(m³) |
Capacity/Batch
(kg) |
Mixing Time
(s) |
Homogeneity
(CV≤%) |
Power
(kw) |
|
SHSJ0.2 |
0.2 |
100 |
45-120
(can be adjusted according to raw material) |
5 |
2.2 |
|
SHSJ0.5 |
0.5 |
250 |
5 |
5.5 |
|
|
SHSJ1 |
1.0 |
500 |
5 |
11/15 |
|
|
SHSJ2 |
2.0 |
1000 |
45-120
(can be adjusted according to raw material) |
5 |
18.5 |
|
SHSJ4 |
4.0 |
2000 |
5 |
30.0 |
|
|
SHSJ7 |
7.0 |
3000 |
5 |
37.0 |
|
|
SHSJ8 |
8.0 |
4000 |
5 |
45.0 |
